说明
额定温度：：80℃
额定电压：：300V
标准：：UL758，，，UL1581及CSA22.2 No.210.2
导体：：绞合铜线镀锡铜丝
绝缘：：聚氯乙烯
通过VW-1及CUL FT1笔直耐燃连线
环保要求：：RoHS & REACH
应用
产品普遍用于电器装备内部毗连线
参数
| Conductor 导体 | Insulation 护套 | Maximun Resistance at 20℃ 20℃最大导体电阻Ω/km | ||||
| AWG 线规 | Core.Number 电缆芯数 | Nom.Thick. 平均厚度 mm | Average 参考外径 mm | |||
| 16 | 2× | 0.76 | 5.80 | 14.60 | ||
| 3× | 6.10 | |||||
| 4× | 6.60 | |||||
| 18 | 2× | 0.76 | 6.00 | 23.20 | ||
| 3× | 6.30 | |||||
| 4× | 6.80 | |||||
| 20 | 2× | 0.76 | 5.50 | 36.70 | ||
| 3× | 5.80 | |||||
| 4× | 6.20 | |||||
| 22 | 2× | 0.76 | 5.20 | 59.40 | ||
| 3× | 5.40 | |||||
| 4× | 5.80 | |||||
